Salwico AC-IR-3Fq, IR Flame Detector (5200236-00A)

Categories: Fire Detection, Flame detectors SKU:

Salwico Addressable/Conventional IR Flame Detector

  • Model : AC-IR-3Fq
  • Part no. 5200236-00A

General Description

  • The AC-IR-3Fq is a triple frequency conventional infrared flame detector produced using the latest in manufacturing technology. It is supplied with an array of advanced features, making it ‘better by design’.
  • The Detector is using infrared elements suitable for the detection of smokeless combustible liquid and gas fires, as well as smoke-forming open fire involving carbonaceous materials as contained in wood, plastics, gases, oil products etc.
  • The Fire evaluation process is done by triple Infrared (3Fq) sensor, protected by a sapphire glass filtering >6.0µm wavelength radiation.
  • Sensor measures the hot carbon dioxide in a specific flame wavelength; the B and C sensors simultaneously measure the interference radiation in near wavelengths.
  • This technique together with intelligent signal processing through microprocessor and custom algorithms, achieves excellent detection reliability while maintaining the highest immunity to interference radiation and sunlight.



Features

  • Triple Frequency IR Detector
  • Low current draw
  • Suitable for installation in damp environment
  • Easy Maintenance
  • Remote LED Option
  • Approved to UNI EN54-10 Ed. 2002

Characteristics

Meausured value: Application domain:

Data

Electrical Specifications : Conventional Mode (incl. Base)

  • Nominal working voltage : 24 VDC
  • Working voltage : 14-30 VDC
  • Working current : 0.45 mA
  • Alarm current : Max 30 mA



Electrical Specifications Addressable Mode (incl. Base)

  • Nominal working voltage : 30 VDC
  • Working voltage : 22-38 VDC
  • Working current : 0.6 mA
  • Alarm current : 1 mA
  • Current when short circuited : 12 mA



Environmental Specifications

  • Application Temperature Range : -25 °C to +75 °C
  • Humidity : Up to 95%
  • Mechanical Information
  • Height : 69 mm (including base)
  • Diameter : 103 mm
  • Weight : 250 g
  • Weight with IP65 Base : 380 g
  • Wire Gauge for Terminals : 2.5 mm2
  • Colour : White  RAL9010
  • Material : Polycarbonate Flame Retarded Cl. UL94V0
  • IP Rating : IP65 (IP67 with locking screws)

To Order Salwico AC-IR-3Fq , Please contact us on below details :

  • Email : info@shipautomation.com
  • Tel : +91 9624 424242
