The Noratel FR60B-400230 is an encapsulated single-phase isolating transformer designed to provide protective electrical separation between the input and output. It has a selectable 400/415/440 V primary and 230 V secondary, with a 40 VA rating and 0.2 A secondary current.
Key Features
- Single-phase galvanic isolation between primary and secondary.
- 400/415/440 V input with 230 V output.
- Compact 40 VA encapsulated construction.
- Double-insulated Class II design.
- Self-extinguishing polyurethane encapsulation.
- IP20 protection against accidental contact.
- Suitable for cabinet and switchboard installation.
- FR60B models support an integrated optional DIN-rail mounting system.
- Designed and tested according to EN 61558-2-4.
- Suitable for installations requiring protective separation between input and output.
- Marine/industrial-oriented construction with DNV, Lloyd’s Register and Bureau Veritas requirements considered.
Typical Applications
- Control-panel power isolation.
- Industrial automation and control cabinets.
- Contactor and relay control circuits.
- Switchboards and electrical distribution panels.
- Industrial processing equipment.
- Marine and shipbuilding electrical installations.
- Applications requiring protective separation between the supply and control circuit.
- Supplying isolated 230 V control or auxiliary circuits.
