Key Features

• High-accuracy laser positioning — provides precise range and bearing measurements to reflective targets.
• Long operating range — nominally 10 m to 3,250 m, depending on target size and atmospheric conditions.
• High laser pulse rate — approximately 30 kHz for rapid target detection and tracking.
• True multi-target tracking — can track multiple targets and provide relative heading information.
• Selectable scanning speed — operator-selectable 1 Hz or 2 Hz rotational scanning.
• Automatic pitch & roll compensation — compensates for vessel motion to maintain reliable target lock in waves.
• Automatic tilt control — active-axis levelling with approximately ±20° roll/pitch tilt compensation.
• False-target rejection — sophisticated tracking algorithms help distinguish intended targets from unwanted reflections.
• Low-sun/bright-light protection — optimized optics improve tracking performance in difficult lighting conditions.
• DP system compatibility — supports multiple serial and Ethernet communication protocols and interfaces with major DP systems.
• User-friendly operator interface — CyScan Dashboard provides control, monitoring and positioning information for the DP operator.
• Tracking and data logging — supports monitoring and recording of positioning information.
• Robust marine construction — IP66-rated enclosure and marine certifications for offshore operation.
• Eye-safe laser — Class 1 laser classification under IEC 60825.
• Multiple target types — compatible with prism clusters, flat targets and cylindrical reflective targets.
• ChartRange™ capability — can provide horizontal distance to reflectors for precision positioning applications.

Typical Applications

• Offshore platform station keeping
• Wind farm vessel operations
• Shuttle tanker loading
• Ship-to-ship operations
• Pipe and cable laying
• ROV and dive support
• Rock dumping
• Replenishment at sea
• Ship-follow and tracking operations
